Fire Class B15 EPS Polyurethane Sandwich Panel 40mm Sound Insulation ODM
| MOQ: | 20T |
| Price: | USD100-800 |
| Standard Packaging: | STEEL PALLET |
| Delivery Period: | 5-8 WEEKS |
| Payment Method: | T/T,L/C |
| Supply Capacity: | 15000TONS PER MONTH |
Detail Information
Place of Origin
China
Brand Name
Wenchen
Certification
ISO, CE
Steel Plate Thickness:
0.3-0.6mm
Panel Width:
1000mm - 1200mm
Fire Class:
B15
Type:
Roof Panel EPS
Foam Thickness:
30mm/40mm/50mm
Desity:
6-25kgs/m³
Eps Thickness:
50-150mm
Steel Sheet Material:
Color Galvanized Steel
Highlight:
EPS polyurethane sandwich panel
,ODM polyurethane sandwich panel
,sound insulation sandwich panel 40mm
Product Description
RAL Color Range Insulated Sandwich Panel
High-performance construction material designed for energy construction projects, offering excellent heat insulation, sound insulation, and fire class B15 with pitch 205mm.
Product Overview
The Insulated Sandwich Panel combines structural strength with superior thermal and acoustic properties, making it ideal for commercial, industrial, and residential buildings requiring energy efficiency and noise reduction.
Key Features
- Product Name: Insulated Sandwich Panel
- Color Options: RAL Color Range Available
- Steel Sheet Material: Color Galvanized Steel
- Steel Plate Thickness: 0.3-0.6mm
- Panel Width: 1000mm - 1200mm
- Fire Class: B15
- High-quality Metal Faced Sandwich Panel for enhanced durability
- Composite Insulated Sandwich Panel designed for superior thermal performance
- Metal Faced Sandwich Panel ensures excellent structural strength and aesthetic appeal
Technical Specifications
| Parameter | Specification |
|---|---|
| Fire Class | B15 |
| Foam Thickness | 30mm / 40mm / 50mm |
| Fire Resistance | Class A1 To B2 (depending on core material) |
| Panel Width | 1000mm - 1200mm |
| Steel Sheet Material | Color Galvanized Steel |
| Purpose | Decorative Finishing |
| Color Options | RAL Color Range Available |
| Advantage | Heat Insulation, Sound Insulation |
| EPS Thickness | 50mm - 150mm |
| Panel Thickness | 30mm - 200mm |
Applications
Wenchen Structural Insulated Sandwich Panels are versatile building materials suitable for cold storage facilities, refrigerated warehouses, industrial buildings, factories, shopping malls, office buildings, and exhibition halls. Their excellent thermal insulation ensures temperature stability while sound insulation minimizes noise pollution.
Customization Options
Wenchen offers comprehensive customization with density range of 6-25kgs/m³, panel width from 1000mm to 1200mm, and length customizable up to 12 meters. Choose from steel plate thickness options of 0.3mm to 0.6mm and fire resistance classifications from Class A1 to B2.
Technical Support & Services
Our comprehensive support includes panel selection guidance, installation procedures, structural calculations, thermal performance analysis, on-site consultation, installation supervision, and maintenance recommendations to ensure optimal performance and longevity.
Packaging & Shipping
Panels are wrapped in protective film, stacked on wooden pallets with corner guards, and shrink-wrapped for maximum protection. We offer sea freight, air freight, and land transportation options with complete documentation for smooth customs clearance.
Frequently Asked Questions
What is an Insulated Sandwich Panel?
A composite building material consisting of two outer metal sheets with an insulating core in between, providing excellent thermal insulation, structural strength, and weather resistance.
What materials are used in Wenchen Insulated Sandwich Panels?
Outer layers made of galvanized steel or aluminum with insulating core materials such as polyurethane (PU), polyisocyanurate (PIR), or expanded polystyrene (EPS).
Where are Wenchen Insulated Sandwich Panels manufactured?
Manufactured in China using advanced production technology to ensure high quality and durability.
What are the typical applications?
Cold storage facilities, warehouses, factories, commercial buildings, and clean rooms due to excellent insulation and structural properties.
How do they contribute to energy efficiency?
The insulating core significantly reduces heat transfer, helping maintain interior temperatures and reducing heating/cooling needs.
